Merge branch 'master' of https://whale.am28.uni-tuebingen.de/git/teaching/scientificComputing

Makefile

@@ -3,7 +3,7 @@ BASENAME=scientificcomputing-script
 SUBDIRS=programming debugging plotting codestyle statistics bootstrap regression likelihood pointprocesses designpattern
 SUBTEXS=$(foreach subd, $(SUBDIRS), $(subd)/lecture/$(subd).tex)

-all : script chapters
+all : plots chapters index script exercises

 chapters :
 	for sd in $(SUBDIRS); do $(MAKE) -C $$sd/lecture chapter; done
@@ -37,6 +37,11 @@ watchpdf :
 watchscript :
 	while true; do ! make -s -q script && make script; sleep 0.5; done

+
+exercises:
+	for sd in $(SUBDIRS); do if test -d $$sd/exercises; then $(MAKE) -C $$sd/exercises pdf; fi; done
+
+
 cleanplots:
 	for sd in $(SUBDIRS); do $(MAKE) -C $$sd/lecture cleanplots; done

@@ -46,6 +51,7 @@ cleantex:

 clean : cleantex
 	for sd in $(SUBDIRS); do $(MAKE) -C $$sd/lecture clean; done
+	for sd in $(SUBDIRS); do if test -d $$sd/exercises; then $(MAKE) -C $$sd/exercises clean; fi; done

 cleanall : clean
 	rm -f $(BASENAME).pdf

README.fonts

@@ -1,6 +1,20 @@
 Fonts for matplotlib
 --------------------

+Install Humor Sans font
+```
+sudo apt install fonts-humor-sans
+```
+
+Clear matplotlib font cache:
+```
+cd ~/.cache/matplotlib/
+rm -r *
+```
+
+Older problems
+--------------
+
 Make sure the right fonts are installed:
 ```
 sudo apt-get install ttf-lyx2.0

bootstrap/code/bootstrapsem.m

@@ -1,7 +1,7 @@
 nsamples = 100;
 nresamples = 1000;

-% draw a SRS (simple random sample, "Stichprobe") from the population:
+% draw a simple random sample ("Stichprobe") from the population:
 x = randn(1, nsamples);
 fprintf('%-30s  %-5s  %-5s  %-5s\n', '', 'mean', 'stdev', 'sem')
 fprintf('%30s  %5.2f  %5.2f  %5.2f\n', 'single SRS', mean(x), std(x), std(x)/sqrt(nsamples))
@@ -15,7 +15,8 @@ for i = 1:nresamples        % loop for generating the bootstraps
 end
 fprintf('%30s  %5.2f  %5.2f  -\n', 'bootstrapped distribution', mean(mus), std(mus))

-% many SRS (we can do that with the random number generator, but not in real life!):
+% many SRS (we can do that with the random number generator,
+% but not in real life!):
 musrs = zeros(nresamples,1);  % vector for the means of each SRS
 for i = 1:nresamples
     x = randn(1, nsamples);   % draw a new SRS

bootstrap/code/meandiffsignificance.m

@@ -0,0 +1,40 @@
+% generate two data sets:
+n = 200;
+d = 0.2;
+x = randn(n, 1);
+y = randn(n, 1) + d;
+
+% difference of sample means:
+md = mean(y) - mean(x);
+fprintf('difference of means of data d = %.2f\n', md);
+
+% distribution of null hypothesis by permutation:
+nperm = 1000;
+xy = [x; y];                         % x and y data in one column vector
+ds = zeros(nperm,1);
+for i = 1:nperm
+    xyr = xy(randperm(length(xy)));  % shuffle data
+    xr = xyr(1:length(x));           % random x-data
+    yr = xyr(length(x)+1:end);       % random y-data
+    ds(i) = mean(yr) - mean(xr);     % difference of means
+end
+[h, b] = hist(ds, 20);
+h = h/sum(h)/(b(2)-b(1));       % normalization
+
+% significance:
+dq = quantile(ds, 0.95);
+fprintf('difference of means of null hypothesis at 5%% significance = %.2f\n', dq);
+if md >= dq
+    fprintf('--> difference of means d=%.2f is significant\n', md);
+else
+    fprintf('--> d=%.2f is not a significant difference of means\n', md);
+end
+
+% plot:
+bar(b, h, 'facecolor', 'b');
+hold on;
+bar(b(b>=dq), h(b>=dq), 'facecolor', 'r');
+plot([md md], [0 4], 'r', 'linewidth', 2);
+xlabel('Difference of means');
+ylabel('Probability density of H0');
+hold off;

bootstrap/code/meandiffsignificance.out

@@ -0,0 +1,4 @@
+>> meandiffsignificance
+difference of means of data d = 0.18
+difference of means of null hypothesis at 5% significance = 0.17
+--> difference of means d=0.18 is significant

bootstrap/exercises/Makefile

@@ -1,34 +1,3 @@
-TEXFILES=$(wildcard exercises??.tex)
+TEXFILES=$(wildcard resampling-?.tex)
-EXERCISES=$(TEXFILES:.tex=.pdf)
-SOLUTIONS=$(EXERCISES:exercises%=solutions%)

-.PHONY: pdf exercises solutions watch watchexercises watchsolutions clean
+include ../../exercises.mk
-
-pdf : $(SOLUTIONS) $(EXERCISES)
-
-exercises : $(EXERCISES)
-
-solutions : $(SOLUTIONS)
-
-$(SOLUTIONS) : solutions%.pdf : exercises%.tex instructions.tex
-	{ echo "\\documentclass[answers,12pt,a4paper,pdftex]{exam}"; sed -e '1d' $<; } > $(patsubst %.pdf,%.tex,$@)
-	pdflatex -interaction=scrollmode $(patsubst %.pdf,%.tex,$@) | tee /dev/stderr | fgrep -q "Rerun to get cross-references right" && pdflatex -interaction=scrollmode $(patsubst %.pdf,%.tex,$@) || true
-	rm $(patsubst %.pdf,%,$@).[!p]*
-
-$(EXERCISES) : %.pdf : %.tex instructions.tex
-	pdflatex -interaction=scrollmode $< | tee /dev/stderr | fgrep -q "Rerun to get cross-references right" && pdflatex -interaction=scrollmode $< || true
-
-watch :
-	while true; do ! make -q pdf && make pdf; sleep 0.5; done
-
-watchexercises :
-	while true; do ! make -q exercises && make exercises; sleep 0.5; done
-
-watchsolutions :
-	while true; do ! make -q solutions && make solutions; sleep 0.5; done
-
-clean :
-	rm -f *~ *.aux *.log *.out
-
-cleanup : clean
-	rm -f $(SOLUTIONS) $(EXERCISES)

bootstrap/exercises/bootstrapmean.m

@@ -10,7 +10,7 @@ function [bootsem, mu] = bootstrapmean(x, resample)
     for i = 1:resample
         % resample:
         xr = x(randi(nsamples, nsamples, 1));
-        % compute statistics on sample:
+        % compute statistics of resampled sample:
         mu(i) = mean(xr);
     end
     bootsem = std(mu);

bootstrap/exercises/correlationbootstrap.m

@@ -25,8 +25,8 @@ end

 %% plot:
 hold on;
-bar(b, h, 'facecolor', [0.5 0.5 0.5]);
+bar(b, h, 'facecolor', [0.5 0.5 0.5]);           % permuation test
-bar(bb, hb, 'facecolor', 'b');
+bar(bb, hb, 'facecolor', 'b');                   % bootstrap
 bar(bb(bb<=rbq), hb(bb<=rbq), 'facecolor', 'r');
 plot([rd rd], [0 4], 'r', 'linewidth', 2);
 xlim([-0.25 0.75])

bootstrap/exercises/correlationsignificance.m

@@ -1,4 +1,4 @@
-%% (a) generate correlated data
+%% (a) generate correlated data:
 n = 1000;
 a = 0.2;
 x = randn(n, 1);

bootstrap/exercises/exercises01.tex

@@ -1,205 +0,0 @@
-\documentclass[12pt,a4paper,pdftex]{exam}
-
-\usepackage[english]{babel}
-\usepackage{pslatex}
-\usepackage[mediumspace,mediumqspace,Gray]{SIunits}      % \ohm, \micro
-\usepackage{xcolor}
-\usepackage{graphicx}
-\usepackage[breaklinks=true,bookmarks=true,bookmarksopen=true,pdfpagemode=UseNone,pdfstartview=FitH,colorlinks=true,citecolor=blue]{hyperref}
-
-%%%%% layout %%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%
-\usepackage[left=20mm,right=20mm,top=25mm,bottom=25mm]{geometry}
-\pagestyle{headandfoot}
-\ifprintanswers
-\newcommand{\stitle}{: Solutions}
-\else
-\newcommand{\stitle}{}
-\fi
-\header{{\bfseries\large Exercise 9\stitle}}{{\bfseries\large Bootstrap}}{{\bfseries\large December 9th, 2019}}
-\firstpagefooter{Prof. Dr. Jan Benda}{Phone: 29 74573}{Email:
-jan.benda@uni-tuebingen.de}
-\runningfooter{}{\thepage}{}
-
-\setlength{\baselineskip}{15pt}
-\setlength{\parindent}{0.0cm}
-\setlength{\parskip}{0.3cm}
-\renewcommand{\baselinestretch}{1.15}
-
-%%%%% listings %%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%
-\usepackage{listings}
-\lstset{
-  language=Matlab,
-  basicstyle=\ttfamily\footnotesize,
-  numbers=left,
-  numberstyle=\tiny,
-  title=\lstname,
-  showstringspaces=false,
-  commentstyle=\itshape\color{darkgray},
-  breaklines=true,
-  breakautoindent=true,
-  columns=flexible,
-  frame=single,
-  xleftmargin=1em,
-  xrightmargin=1em,
-  aboveskip=10pt
-}
-
-%%%%% math stuff: %%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%
-\usepackage{amsmath}
-\usepackage{amssymb}
-\usepackage{bm}
-\usepackage{dsfont}
-\newcommand{\naZ}{\mathds{N}}
-\newcommand{\gaZ}{\mathds{Z}}
-\newcommand{\raZ}{\mathds{Q}}
-\newcommand{\reZ}{\mathds{R}}
-\newcommand{\reZp}{\mathds{R^+}}
-\newcommand{\reZpN}{\mathds{R^+_0}}
-\newcommand{\koZ}{\mathds{C}}
-
-%%%%% page breaks %%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%
-\newcommand{\continue}{\ifprintanswers%
-\else
-\vfill\hspace*{\fill}$\rightarrow$\newpage%
-\fi}
-\newcommand{\continuepage}{\ifprintanswers%
-\newpage
-\else
-\vfill\hspace*{\fill}$\rightarrow$\newpage%
-\fi}
-\newcommand{\newsolutionpage}{\ifprintanswers%
-\newpage%
-\else
-\fi}
-
-%%%%% new commands %%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%
-\newcommand{\qt}[1]{\textbf{#1}\\}
-\newcommand{\pref}[1]{(\ref{#1})}
-\newcommand{\extra}{--- Zusatzaufgabe ---\ \mbox{}}
-\newcommand{\code}[1]{\texttt{#1}}
-
-
-%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%
-\begin{document}
-
-\input{instructions}
-
-\begin{questions}
-
-\question \qt{Bootstrap the standard error of the mean}
-We want to compute the standard error of the mean of a data set by
-means of the bootstrap method and compare the result with the formula
-``standard deviation divided by the square-root of $n$''.
-\begin{parts}
-  \part Download the file \code{thymusglandweights.dat} from Ilias.
-  This is a data set of the weights of the thymus glands of 14-day old chicken embryos
-  measured in milligram.
-  \part Load the data into Matlab (\code{load} function).
-  \part Compute histogram, mean, and standard error of the mean of the first 80 data points.
-  \part Compute the standard error of the mean of the first 80 data
-  points by bootstrapping the data 500 times. Write a function that
-  bootstraps the standard error of the mean of a given data set. The
-  function should also return a vector with the bootstrapped means.
-  \part Compute the 95\,\% confidence interval for the mean from the
-  bootstrap distribution (\code{quantile()} function) --- the
-  interval that contains the true mean with 95\,\% probability.
-  \part Use the whole data set and the bootstrap method for computing
-  the dependence of the standard error of the mean from the sample
-  size $n$.
-  \part Compare your result with the formula for the standard error
-  $\sigma/\sqrt{n}$.
-\end{parts}
-\begin{solution}
-  \lstinputlisting{bootstrapmean.m}
-  \lstinputlisting{bootstraptymus.m}
-  \includegraphics[width=0.5\textwidth]{bootstraptymus-datahist}
-  \includegraphics[width=0.5\textwidth]{bootstraptymus-meanhist}
-  \includegraphics[width=0.5\textwidth]{bootstraptymus-samples}
-\end{solution}
-
-
-\question \qt{Student t-distribution}
-The distribution of Student's t, $t=\bar x/(\sigma_x/\sqrt{n})$, the
-estimated mean $\bar x$ of a data set of size $n$ divided by the
-estimated standard error of the mean $\sigma_x/\sqrt{n}$, where
-$\sigma_x$ is the estimated standard deviation, is not a normal
-distribution but a Student-t distribution.  We want to compute the
-Student-t distribution and compare it with the normal distribution.
-\begin{parts}
-\part Generate 100000 normally distributed random numbers.
-\part Draw from these data 1000 samples of size $n=3$, 5, 10, and
-50. For each sample size $n$ ...
-\part ... compute the mean $\bar x$ of the samples and plot the
-probability density of these means.
-\part ... compare the resulting probability densities with corresponding
-normal distributions.
-\part ... compute Student's $t=\bar x/(\sigma_x/\sqrt{n})$ and compare its
-distribution with the normal distribution with standard deviation of
-one. Is $t$ normally distributed? Under which conditions is $t$
-normally distributed?
-\end{parts}
-\newsolutionpage
-\begin{solution}
-  \lstinputlisting{tdistribution.m}
-  \includegraphics[width=1\textwidth]{tdistribution-n03}\\
-  \includegraphics[width=1\textwidth]{tdistribution-n05}\\
-  \includegraphics[width=1\textwidth]{tdistribution-n10}\\
-  \includegraphics[width=1\textwidth]{tdistribution-n50}
-\end{solution}
-
-
-\continue
-\question \qt{Permutation test} \label{permutationtest}
-We want to compute the significance of a correlation by means of a permutation test.
-\begin{parts}
-  \part \label{permutationtestdata} Generate 1000 correlated pairs
-  $x$, $y$ of random numbers according to:
-\begin{verbatim}
-n = 1000
-a = 0.2;
-x = randn(n, 1);
-y = randn(n, 1) + a*x;
-\end{verbatim}
-  \part Generate a scatter plot of the two variables.
-  \part Why is $y$ correlated with $x$?
-  \part Compute the correlation coefficient between $x$ and $y$.
-  \part What do you need to do in order to destroy the correlations between the $x$-$y$ pairs?
-  \part Do exactly this 1000 times and compute each time the correlation coefficient.
-  \part Compute and plot the probability density of these correlation
-  coefficients.
-  \part Is the correlation of the original data set significant?
-  \part What does ``significance of the correlation'' mean?
-%  \part Vary the sample size \code{n} and compute in the same way the
-%  significance of the correlation.
-\end{parts}
-\begin{solution}
-  \lstinputlisting{correlationsignificance.m}
-  \includegraphics[width=1\textwidth]{correlationsignificance}
-\end{solution}
-
-\question \qt{Bootstrap the correlation coefficient}
-The permutation test generates the distribution of the null hypothesis
-of uncorrelated data and we check whether the correlation coefficient
-of the data differs significantly from this
-distribution. Alternatively we can bootstrap the data while keeping
-the pairs and determine the confidence interval of the correlation
-coefficient of the data. If this differs significantly from a
-correlation coefficient of zero we can conclude that the correlation
-coefficient of the data indeed quantifies correlated data.
-
-We take the same data set that we have generated in exercise
-\ref{permutationtest} (\ref{permutationtestdata}).
-\begin{parts}
-  \part Bootstrap 1000 times the correlation coefficient from the data.
-  \part Compute and plot the probability density of these correlation
-  coefficients.
-  \part Is the correlation of the original data set significant?
-\end{parts}
-\begin{solution}
-  \lstinputlisting{correlationbootstrap.m}
-  \includegraphics[width=1\textwidth]{correlationbootstrap}
-\end{solution}
-
-\end{questions}
-
-\end{document}

bootstrap/exercises/instructions.tex

@@ -1,6 +0,0 @@
-\vspace*{-7.8ex}
-\begin{center}
-\textbf{\Large Introduction to Scientific Computing}\\[2.3ex]
-{\large Jan Grewe, Jan Benda}\\[-3ex]
-Neuroethology Lab \hfill --- \hfill Institute for Neurobiology \hfill --- \hfill \includegraphics[width=0.28\textwidth]{UT_WBMW_Black_RGB} \\
-\end{center}

bootstrap/exercises/meandiffpermutation.m

@@ -0,0 +1,29 @@
+function [md, ds, dq] = meandiffpermutation(x, y, nperm, alpha)
+% Permutation test for difference of means of two independent samples.
+%
+% [md, ds, dq] = meandiffpermutation(x, y, nperm, alpha);
+%
+% Arguments:
+%   x: vector with the samples of the x data set.
+%   y: vector with the samples of the y data set.
+%   nperm: number of permutations run.
+%   alpha: significance level.
+%
+% Returns:
+%   md: difference of the means
+%   ds: vector containing the differences of the means of the resampled data sets
+%   dq: difference of the means at a significance of alpha.
+
+  md = mean(x) - mean(y);             % measured difference
+  xy = [x; y];                        % merge data sets
+  % permutations:
+  ds = zeros(nperm, 1);
+  for i = 1:nperm
+      xyr = xy(randperm(length(xy))); % shuffle xy
+      xr = xyr(1:length(x));          % random x sample
+      yr = xyr(length(x)+1:end);      % random y sample
+      ds(i) = mean(xr) - mean(yr);
+  end
+  % significance:
+  dq = quantile(ds, 1.0 - alpha);
+end

bootstrap/exercises/meandiffplot.m

@@ -0,0 +1,42 @@
+function meandiffplot(x, y, md, ds, dq, k, nrows)
+% Plot histogram of data sets and of null hypothesis for differences in mean.
+%
+% meandiffplot(x, y, md, ds, dq, k, rows);
+%
+% Arguments:
+%   x: vector with the samples of the x data set.
+%   y: vector with the samples of the y data set.
+%   md: difference of means of the two data sets.
+%   ds: vector containing the differences of the means of the resampled data sets
+%   dq: minimum difference of the means considered significant.
+%   k: current row for the plot panels.
+%   nrows: number of rows of panels in the figure.
+
+  %% (b) plot histograms:
+  subplot(nrows, 2, k*2-1);
+  bmin = min([x; y]);
+  bmax = max([x; y]);
+  bins = bmin:(bmax-bmin)/20.0:bmax;
+  [xh, b] = hist(x, bins);
+  [yh, b] = hist(y, bins);
+  bar(bins, xh, 'facecolor', 'b')
+  hold on
+  bar(bins, yh, 'facecolor', 'r');
+  xlabel('x and y [mV]')
+  ylabel('counts')
+  hold off
+
+  %% (f) pdf of the differences:
+  [h, b] = hist(ds, 20);
+  h = h/sum(h)/(b(2)-b(1));           % normalization
+
+  %% plot:
+  subplot(nrows, 2, k*2)
+  bar(b, h, 'facecolor', 'b');
+  hold on;
+  bar(b(b>=dq), h(b>=dq), 'facecolor', 'r');
+  plot([md md], [0 4], 'r', 'linewidth', 2);
+  xlabel('Difference of means [mV]');
+  ylabel('pdf of H0');
+  hold off;
+end

bootstrap/exercises/meandiffsignificance.m

@@ -0,0 +1,37 @@
+n = 200;
+mx = -40.0;
+nperm = 1000;
+alpha = 0.05;
+
+%% (h) repeat for various means of the y-data set:
+mys = [-40.1, -40.2, -40.5];
+for k=1:length(mys)
+
+  %% (a) generate data:
+  my = mys(k);
+  x = randn(n, 1) + mx;
+  y = randn(n, 1) + my;
+
+  %% (d), (e) permutation test:
+  [md, ds, dq] = meandiffpermutation(x, y, nperm, alpha);
+
+  %% (c) difference of means:
+  fprintf('\nmean x = %.1fmV, mean y = %.1fmV\n', mx, my);
+  fprintf('  difference of means = %.2fmV\n', md);
+
+  %% (g) significance:
+  fprintf('  difference of means at 5%% significance = %.2fmV\n', dq);
+  if md >= dq
+      fprintf('  --> measured difference of means is significant\n');
+  else
+      fprintf('  --> measured difference of means is not significant\n');
+  end
+
+  %% (b), (f) plot histograms of data and pdf of differences:
+  meandiffplot(x, y, md, ds, dq, k, length(mys));
+
+  subplot(length(mys), 2, k*2-1);
+  title(sprintf('mx=%.1fmV, my=%.1fmV', mx, my))
+end
+
+savefigpdf(gcf, 'meandiffsignificance.pdf', 12, 10);

bootstrap/exercises/resampling-1.tex

@@ -0,0 +1,116 @@
+\documentclass[12pt,a4paper,pdftex]{exam}
+
+\newcommand{\exercisetopic}{Resampling}
+\newcommand{\exercisenum}{8}
+\newcommand{\exercisedate}{December 14th, 2020}
+
+\input{../../exercisesheader}
+
+\firstpagefooter{Prof. Dr. Jan Benda}{}{jan.benda@uni-tuebingen.de}
+
+%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%
+\begin{document}
+
+\input{../../exercisestitle}
+
+\begin{questions}
+
+%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%
+\question \qt{Read chapter 7 of the script on ``resampling methods''!}\vspace{-3ex}
+
+\question \qt{Permutation test of correlations} \label{correlationtest}
+We want to compute the significance of a correlation by means of a permutation test.
+\begin{parts}
+  \part \label{correlationtestdata} Generate 1000 correlated pairs
+  $x$, $y$ of random numbers according to:
+\begin{verbatim}
+n = 1000
+a = 0.2;
+x = randn(n, 1);
+y = randn(n, 1) + a*x;
+\end{verbatim}
+  \part Generate a scatter plot of the two variables.
+  \part Why is $y$ correlated with $x$?
+  \part Compute the correlation coefficient between $x$ and $y$.
+  \part What do you need to do in order to destroy the correlations between the $x$-$y$ pairs?
+  \part Do exactly this 1000 times and compute each time the correlation coefficient.
+  \part Compute and plot the probability density of these correlation
+  coefficients.
+  \part Is the correlation of the original data set significant?
+  \part What does ``significance of the correlation'' mean?
+%  \part Vary the sample size \code{n} and compute in the same way the
+%  significance of the correlation.
+\end{parts}
+\begin{solution}
+  \lstinputlisting{correlationsignificance.m}
+  \includegraphics[width=1\textwidth]{correlationsignificance}
+\end{solution}
+
+\newsolutionpage
+\question \qt{Bootstrap the correlation coefficient}
+The permutation test generates the distribution of the null hypothesis
+of uncorrelated data and we check whether the correlation coefficient
+of the data differs significantly from this
+distribution. Alternatively we can bootstrap the data while keeping
+the pairs and determine the confidence interval of the correlation
+coefficient of the data. If this differs significantly from a
+correlation coefficient of zero we can conclude that the correlation
+coefficient of the data indeed quantifies correlated data.
+
+We take the same data set that we have generated in exercise
+\ref{correlationtest} (\ref{correlationtestdata}).
+\begin{parts}
+  \part Bootstrap 1000 times the correlation coefficient from the
+  data, i.e.  generate bootstrap data by randomly resampling the
+  original data pairs with replacement. Use the \code{randi()}
+  function for generating random indices that you can use to select a
+  random sample from the original data.
+  \part Compute and plot the probability density of these correlation
+  coefficients.
+  \part Is the correlation of the original data set significant?
+\end{parts}
+\begin{solution}
+  \lstinputlisting{correlationbootstrap.m}
+  \includegraphics[width=1\textwidth]{correlationbootstrap}
+\end{solution}
+
+
+\continue
+\question \qt{Permutation test of difference of means}
+We want to test whether two data sets come from distributions that
+differ in their mean by means of a permutation test.
+\begin{parts}
+  \part Generate two normally distributed data sets $x$ and $y$
+  containing each $n=200$ samples. Let's assume the $x$ samples are
+  measurements of the membrane potential of a mammalian photoreceptor
+  in darkness with a mean of $-40$\,mV and a standard deviation of
+  1\,mV. The $y$ values are the membrane potentials measured under dim
+  illumination and come from a distribution with the same standard
+  deviation and a mean of $-40.5$\,mV. See section 5.2 ``Scaling and
+  shifting random numbers'' in the script.
+  \part Plot histograms of the $x$ and $y$ data in a single
+  plot. Choose appropriate bins.
+  \part Compute the means of $x$ and $y$ and their difference.
+  \part The null hypothesis is that the $x$ and $y$ data come from the
+  same distribution. How can you generate new samples $x_r$ and $y_r$
+  from the original data that come from the same distribution?
+  \part Do exactly this 1000 times and compute each time the
+  difference of the means of the two resampled samples.
+  \part Compute and plot the probability density of the resulting
+  distribution of the null hypothesis.
+  \part Is the difference of the means of the original data sets significant?
+  \part Repeat this procedure for $y$ samples that are closer or
+  further apart from the mean of the $x$ data set. For this put the
+  computations of the permuation test in a function and all the plotting
+  in another function.
+\end{parts}
+\begin{solution}
+  \lstinputlisting{meandiffpermutation.m}
+  \lstinputlisting{meandiffplot.m}
+  \lstinputlisting{meandiffsignificance.m}
+  \includegraphics[width=1\textwidth]{meandiffsignificance}
+\end{solution}
+
+\end{questions}
+
+\end{document}

bootstrap/exercises/resampling-2.tex

@@ -0,0 +1,84 @@
+\documentclass[12pt,a4paper,pdftex]{exam}
+
+\newcommand{\exercisetopic}{Resampling}
+\newcommand{\exercisenum}{X2}
+\newcommand{\exercisedate}{December 14th, 2020}
+
+\input{../../exercisesheader}
+
+\firstpagefooter{Prof. Dr. Jan Benda}{}{jan.benda@uni-tuebingen.de}
+
+%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%
+\begin{document}
+
+\input{../../exercisestitle}
+
+\begin{questions}
+
+%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%
+\question \qt{Read chapter 7 of the script on ``resampling methods''!}\vspace{-3ex}
+
+\question \qt{Bootstrap the standard error of the mean}
+We want to compute the standard error of the mean of a data set by
+means of the bootstrap method and compare the result with the formula
+``standard deviation divided by the square-root of $n$''.
+\begin{parts}
+  \part Download the file \code{thymusglandweights.dat} from Ilias.
+  This is a data set of the weights of the thymus glands of 14-day old chicken embryos
+  measured in milligram.
+  \part Load the data into Matlab (\code{load} function).
+  \part Compute histogram, mean, and standard error of the mean of the first 80 data points.
+  \part Compute the standard error of the mean of the first 80 data
+  points by bootstrapping the data 500 times. Write a function that
+  bootstraps the standard error of the mean of a given data set. The
+  function should also return a vector with the bootstrapped means.
+  \part Compute the 95\,\% confidence interval for the mean from the
+  bootstrap distribution (\code{quantile()} function) --- the
+  interval that contains the true mean with 95\,\% probability.
+  \part Use the whole data set and the bootstrap method for computing
+  the dependence of the standard error of the mean from the sample
+  size $n$.
+  \part Compare your result with the formula for the standard error
+  $\sigma/\sqrt{n}$.
+\end{parts}
+\begin{solution}
+  \lstinputlisting{bootstrapmean.m}
+  \lstinputlisting{bootstraptymus.m}
+  \includegraphics[width=0.5\textwidth]{bootstraptymus-datahist}
+  \includegraphics[width=0.5\textwidth]{bootstraptymus-meanhist}
+  \includegraphics[width=0.5\textwidth]{bootstraptymus-samples}
+\end{solution}
+
+
+\question \qt{Student t-distribution}
+The distribution of Student's t, $t=\bar x/(\sigma_x/\sqrt{n})$, the
+estimated mean $\bar x$ of a data set of size $n$ divided by the
+estimated standard error of the mean $\sigma_x/\sqrt{n}$, where
+$\sigma_x$ is the estimated standard deviation, is not a normal
+distribution but a Student-t distribution.  We want to compute the
+Student-t distribution and compare it with the normal distribution.
+\begin{parts}
+\part Generate 100000 normally distributed random numbers.
+\part Draw from these data 1000 samples of size $n=3$, 5, 10, and
+50. For each sample size $n$ ...
+\part ... compute the mean $\bar x$ of the samples and plot the
+probability density of these means.
+\part ... compare the resulting probability densities with corresponding
+normal distributions.
+\part ... compute Student's $t=\bar x/(\sigma_x/\sqrt{n})$ and compare its
+distribution with the normal distribution with standard deviation of
+one. Is $t$ normally distributed? Under which conditions is $t$
+normally distributed?
+\end{parts}
+\newsolutionpage
+\begin{solution}
+  \lstinputlisting{tdistribution.m}
+  \includegraphics[width=1\textwidth]{tdistribution-n03}\\
+  \includegraphics[width=1\textwidth]{tdistribution-n05}\\
+  \includegraphics[width=1\textwidth]{tdistribution-n10}\\
+  \includegraphics[width=1\textwidth]{tdistribution-n50}
+\end{solution}
+
+\end{questions}
+
+\end{document}

bootstrap/exercises/tdistribution.m

@@ -4,7 +4,7 @@ x=randn(n, 1);

 for nsamples = [3 5 10 50]
     nsamples
-    %% compute mean, standard deviation and t:
+    % compute mean, standard deviation and t:
     nmeans = 10000;
     means = zeros(nmeans, 1);
     sdevs = zeros(nmeans, 1);
@@ -26,7 +26,7 @@ for nsamples=[3 5 10 50]
     pm = exp(-0.5*(xg/msdev).^2)/sqrt(2.0*pi)/msdev;
     pt = exp(-0.5*(xg/tsdev).^2)/sqrt(2.0*pi)/tsdev;

-    %% plots
+    % plots:
     subplot(1, 2, 1)
     bins = xmin:0.2:xmax;
     [h,b] = hist(means, bins);

bootstrap/lecture/bootstrap-chapter.tex

@@ -10,6 +10,8 @@
 \setcounter{page}{\pagenumber}
 \setcounter{chapter}{\chapternumber}

+\renewcommand{\exercisesolutions}{here}  % 0: here, 1: chapter, 2: end
+
 %%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%
 %%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%
 \begin{document}
@@ -17,10 +19,20 @@
 \include{bootstrap}

 \section{TODO}
+
 This chapter easily covers two lectures:
 \begin{itemize}
 \item 1. Bootstrapping with a proper introduction of of confidence intervals
-\item 2. Permutation test with a proper introduction of statistical tests (dsitribution of nullhypothesis, significance, power, etc.)
+\item 2. Permutation test with a proper introduction of statistical tests (distribution of nullhypothesis, significance, power, etc.)
+\end{itemize}
+ToDo:
+\begin{itemize}
+\item Add jacknife methods to bootstrapping
+\item Add discussion of confidence intervals to descriptive statistics chapter
+\item Have a separate chapter on statistical tests before. What is the
+  essence of a statistical test (null hypothesis distribution), power
+  analysis, and a few examples of existing functions for statistical
+  tests.
 \end{itemize}

 \end{document}

bootstrap/lecture/bootstrap.tex

@@ -1,20 +1,28 @@
 %%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%
 %%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%
-\chapter{Bootstrap methods}
+\chapter{Resampling methods}
 \label{bootstrapchapter}
-\exercisechapter{Bootstrap methods}
+\exercisechapter{Resampling methods}

-Bootstrapping methods are applied to create distributions of
+
-statistical measures via resampling of a sample. Bootstrapping offers several
+\entermde{Resampling methoden}{Resampling methods} are applied to
-advantages:
+generate distributions of statistical measures via resampling of
+existing samples. Resampling offers several advantages:
 \begin{itemize}
 \item Fewer assumptions (e.g. a measured sample does not need to be
   normally distributed).
 \item Increased precision as compared to classical methods. %such as?
-\item General applicability: the bootstrapping methods are very
+\item General applicability: the resampling methods are very
   similar for different statistics and there is no need to specialize
   the method to specific statistic measures.
 \end{itemize}
+Resampling methods can be used for both estimating the precision of
+estimated statistics (e.g. standard error of the mean, confidence
+intervals) and testing for significane.
+
+
+%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%
+\section{Bootstrapping}

 \begin{figure}[tp]
   \includegraphics[width=0.8\textwidth]{2012-10-29_16-26-05_771}\\[2ex]
@@ -84,19 +92,20 @@ of the statistical population. We can use the bootstrap distribution
 to draw conclusion regarding the precision of our estimation (e.g.
 standard errors and confidence intervals).

-Bootstrapping methods create bootstrapped samples from a SRS by
+Bootstrapping methods generate bootstrapped samples from a SRS by
 resampling. The bootstrapped samples are used to estimate the sampling
 distribution of a statistical measure. The bootstrapped samples have
-the same size as the original sample and are created by randomly
+the same size as the original sample and are generated by randomly
 drawing with replacement. That is, each value of the original sample
-can occur once, multiple time, or not at all in a bootstrapped
+can occur once, multiple times, or not at all in a bootstrapped
 sample. This can be implemented by generating random indices into the
 data set using the \code{randi()} function.


-\section{Bootstrap of the standard error}
+%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%
+\subsection{Bootstrap the standard error}

-Bootstrapping can be nicely illustrated at the example of the
+Bootstrapping can be nicely illustrated on the example of the
 \enterm{standard error} of the mean (\determ{Standardfehler}). The
 arithmetic mean is calculated for a simple random sample. The standard
 error of the mean is the standard deviation of the expected
@@ -116,11 +125,10 @@ population.
     the standard error of the mean.}
 \end{figure}

-Via bootstrapping we create a distribution of the mean values
+Via bootstrapping we generate a distribution of mean values
 (\figref{bootstrapsemfig}) and the standard deviation of this
-distribution is the standard error of the mean.
+distribution is the standard error of the sample mean.

-\pagebreak[4]
 \begin{exercise}{bootstrapsem.m}{bootstrapsem.out}
   Create the distribution of mean values from bootstrapped samples
   resampled from a single SRS. Use this distribution to estimate the
@@ -138,68 +146,166 @@ distribution is the standard error of the mean.
 \end{exercise}


+%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%
 \section{Permutation tests}
+
 Statistical tests ask for the probability of a measured value to
 originate from a null hypothesis. Is this probability smaller than the
 desired \entermde{Signifikanz}{significance level}, the
-\entermde{Nullhypothese}{null hypothesis} may be rejected.
+\entermde{Nullhypothese}{null hypothesis} can be rejected.

 Traditionally, such probabilities are taken from theoretical
-distributions which are based on assumptions about the data.  Thus the
+distributions which have been derived based on some assumptions about
-applied statistical test has to be appropriate for the type of
+the data. For example, the data should be normally distributed.  Given
-data. An alternative approach is to calculate the probability density
+some data one has to find an appropriate test that matches the
-of the null hypothesis directly from the data itself. To do this, we
+properties of the data. An alternative approach is to calculate the
-need to resample the data according to the null hypothesis from the
+probability density of the null hypothesis directly from the data
-SRS. By such permutation operations we destroy the feature of interest
+themselves. To do so, we need to resample the data according to the
-while we conserve all other statistical properties of the data.
+null hypothesis from the SRS. By such permutation operations we
+destroy the feature of interest while conserving all other statistical
+properties of the data.
+
+
+\subsection{Significance of a difference in the mean}
+
+Often we would like to know whether two data sets differ in their
+mean. Whether the ears of foxes are larger in southern Europe compared
+to the ones from Scandinavia, whether a drug decreases blood pressure
+in humans, whether a sensory stimulus increases the firing rate of a
+neuron, etc. The \entermde{Nullhypothese}{null hypothesis} is that
+they do not differ in their means, i.e. that both data sets come from
+the same distribution. But even if the two data sets come from the
+same distribution, their sample means may nevertheless differ by
+chance. We need to figure out how these differences of the means are
+distributed. Only if the measured difference between the means is
+significantly larger than the ones obtained by chance we can reject
+the null hypothesis and consider the two data sets to differ
+significantly in their means.
+
+We can easily estimate the distribution of the null hypothesis by
+putting the data of both data sets in one big bag. By merging the two
+data sets we assume that all the data values come from the same
+distribution. We then randomly separate the data values into two new
+data sets. These random data sets contain data from both original data
+sets and thus come from the same distribution. From these random data
+sets we compute the difference of their sample means. This procedure
+is repeated many, say one thousand, times and each time we get a value
+for a difference of means. The distribution of these values is the
+distribution of the null hypothesis. It is the distribution of
+differences of mean values that we get by chance although the two data
+sets come from the same distribution. For a one-sided test that checks
+whether the measured difference of means is significantly larger than
+zero at a significance level of 5\,\% we compute the value of the
+95\,\% percentile of the null distribution. If the measured value is
+larger, we can reject the null hypothesis and consider the two data
+sets to differ significantly in their means.
+
+By using the original data to estimate the null hypothesis, we make no
+assumption about the properties of the data. We do not need to worry
+about the data being normally distributed. We do not need to memorize
+which test to use in which situation. And we better understand what we
+are testing, because we design the test ourselves. Nowadays, computer
+are powerful enough to iterate even ten thousand times over the data
+to compute the distribution of the null hypothesis --- with only a few
+lines of code. This is why \entermde{Permutationstest}{permutaion
+  test} are getting quite popular.

 \begin{figure}[tp]
-  \includegraphics[width=1\textwidth]{permutecorrelation}
+  \includegraphics[width=1\textwidth]{permuteaverage}
-  \titlecaption{\label{permutecorrelationfig}Permutation test for
+  \titlecaption{\label{permuteaverage}Permutation test for differences
-    correlations.}{Let the correlation coefficient of a dataset with
+    in means.}{We want to test whether two datasets
-    200 samples be $\rho=0.21$. The distribution of the null
+    $\left\{x_i\right\}$ (red) and $\left\{y_i\right\}$ (blue) come
-    hypothesis (yellow), optained from the correlation coefficients of
+    from different distributions by assessing the significance of the
-    permuted and therefore uncorrelated datasets is centered around
+    difference in their sample means. The data sets were generated
-    zero. The measured correlation coefficient is larger than the
+    with a difference in their population means of $d=0.7$. For
-    95\,\% percentile of the null hypothesis. The null hypothesis may
+    generating the distribution of the null hypothesis, i.e. the
-    thus be rejected and the measured correlation is considered
+    distribution of differences in the means if the two data sets come
-    statistically significant.}
+    from the same distribution, we randomly select the same number of
+    samples from both data sets (top right). This is repeated many
+    times and results in the desired distribution of differences of
+    means (bottom). The measured difference is clearly beyond the
+    95\,\% percentile of this distribution and thus indicates a
+    significant difference between the distributions of the two
+    original data sets.}
 \end{figure}

-A good example for the application of a
+\begin{exercise}{meandiffsignificance.m}{meandiffsignificance.out}
-\entermde{Permutationstest}{permutaion test} is the statistical
+Estimate the statistical significance of a difference in the mean of two data sets.
-assessment of \entermde[correlation]{Korrelation}{correlations}. Given
+\vspace{-1ex}
-are measured pairs of data points $(x_i, y_i)$. By calculating the
+\begin{enumerate}
+\item Generate two independent data sets, $\left\{x_i\right\}$ and
+  $\left\{y_i\right\}$, of $n=200$ samples each, by drawing random
+  numbers from a normal distribution. Add 0.2 to all the $y_i$ samples
+  to ensure the population means to differ by 0.2.
+\item Calculate the difference between the sample means of the two data sets.
+\item Estimate the distribution of the null hypothesis of no
+  difference of the means by generating new data sets with the same
+  number of samples randomly selected from both data sets.  For this
+  lump the two data sets together into a single vector. Then permute
+  the order of the elements in this vector using the function
+  \varcode{randperm()}, split it into two data sets and calculate
+  the difference of their means. Repeat this 1000 times.
+\item Read out the 95\,\% percentile from the resulting distribution
+  of the differences in the mean, the null hypothesis using the
+  \varcode{quantile()} function, and compare it with the difference of
+  means measured from the original data sets.
+\end{enumerate}
+\end{exercise}
+
+
+\subsection{Significance of correlations}
+
+Another nice example for the application of a
+\entermde{Permutationstest}{permutaion test} is testing for
+significant \entermde[correlation]{Korrelation}{correlations}
+(figure\,\ref{permutecorrelationfig}). Given are measured pairs of
+data points $(x_i, y_i)$. By calculating the
 \entermde[correlation!correlation
-coefficient]{Korrelationskoeffizient}{correlation
+coefficient]{Korrelationskoeffizient}{correlation coefficient} we can
-  coefficient} we can quantify how strongly $y$ depends on $x$. The
+quantify how strongly $y$ depends on $x$. The correlation coefficient
-correlation coefficient alone, however, does not tell whether the
+alone, however, does not tell whether the correlation is significantly
-correlation is significantly different from a random correlation. The
+different from a non-zero correlation that we might get although there
-\entermde{Nullhypothese}{null hypothesis} for such a situation is that
+is no true correlation in the data. The \entermde{Nullhypothese}{null
-$y$ does not depend on $x$. In order to perform a permutation test, we
+  hypothesis} for such a situation is that $y$ does not depend on
-need to destroy the correlation by permuting the $(x_i, y_i)$ pairs,
+$x$. In order to perform a permutation test, we need to destroy the
-i.e. we rearrange the $x_i$ and $y_i$ values in a random
+correlation between the data pairs by permuting the $(x_i, y_i)$
+pairs, i.e. we rearrange the $x_i$ and $y_i$ values in a random
 fashion. Generating many sets of random pairs and computing the
-resulting correlation coefficients yields a distribution of
+corresponding correlation coefficients yields a distribution of
-correlation coefficients that result randomly from uncorrelated
+correlation coefficients that result randomly from truly uncorrelated
 data. By comparing the actually measured correlation coefficient with
 this distribution we can directly assess the significance of the
-correlation (figure\,\ref{permutecorrelationfig}).
+correlation.
+
+\begin{figure}[tp]
+  \includegraphics[width=1\textwidth]{permutecorrelation}
+  \titlecaption{\label{permutecorrelationfig}Permutation test for
+    correlations.}{Let the correlation coefficient of a dataset with
+    200 samples be $\rho=0.21$ (top left). By shuffling the data pairs
+    we destroy any true correlation (top right). The resulting
+    distribution of the null hypothesis (bottm, yellow), optained from
+    the correlation coefficients of permuted and therefore
+    uncorrelated datasets is centered around zero. The measured
+    correlation coefficient is larger than the 95\,\% percentile of
+    the null hypothesis. The null hypothesis may thus be rejected and
+    the measured correlation is considered statistically significant.}
+\end{figure}

 \begin{exercise}{correlationsignificance.m}{correlationsignificance.out}
 Estimate the statistical significance of a correlation coefficient.
 \begin{enumerate}
-\item Create pairs of $(x_i, y_i)$ values. Randomly choose $x$-values
+\item Generate pairs of $(x_i, y_i)$ values. Randomly choose $x$-values
   and calculate the respective $y$-values according to $y_i =0.2 \cdot x_i + u_i$
   where $u_i$ is a random number drawn from a normal distribution.
 \item Calculate the correlation coefficient.
-\item Generate the distribution of the null hypothesis by generating
+\item Estimate the distribution of the null hypothesis by generating
   uncorrelated pairs. For this permute $x$- and $y$-values
   \matlabfun{randperm()} 1000 times and calculate for each permutation
   the correlation coefficient.
 \item Read out the 95\,\% percentile from the resulting distribution
-  of the null hypothesis and compare it with the correlation
+  of the null hypothesis using the \varcode{quantile()} function and
-  coefficient computed from the original data.
+  compare it with the correlation coefficient computed from the
+  original data.
 \end{enumerate}
 \end{exercise}


bootstrap/lecture/bootstrapsem.py

@@ -24,7 +24,7 @@ for i in range(nresamples) :
     musrs.append(np.mean(rng.randn(nsamples)))
 hmusrs, _ = np.histogram(musrs, bins, density=True)

-fig, ax = plt.subplots(figsize=cm_size(figure_width, 1.2*figure_height))
+fig, ax = plt.subplots(figsize=cm_size(figure_width, 1.05*figure_height))
 fig.subplots_adjust(**adjust_fs(left=4.0, bottom=2.7, right=1.5))
 ax.set_xlabel('Mean')
 ax.set_xlim(-0.4, 0.4)

bootstrap/lecture/permuteaverage.py

@@ -0,0 +1,103 @@
+import numpy as np
+import scipy.stats as st
+import matplotlib.pyplot as plt
+import matplotlib.gridspec as gridspec
+import matplotlib.ticker as ticker
+from plotstyle import *
+
+rng = np.random.RandomState(637281)
+
+# generate data that differ in their mein by d:
+n = 200
+d = 0.7
+x = rng.randn(n) + d;
+y = rng.randn(n);
+#x = rng.exponential(1.0, n);
+#y = rng.exponential(1.0, n) + d;
+
+# histogram of data:
+db = 0.5
+bins = np.arange(-2.5, 2.6, db)
+hx, _ = np.histogram(x, bins)
+hy, _ = np.histogram(y, bins)
+
+# Diference of means, pooled standard deviation and Cohen's d:
+ad = np.mean(x)-np.mean(y)
+s = np.sqrt(((len(x)-1)*np.var(x)+(len(y)-1)*np.var(y))/(len(x)+len(y)-2))
+cd = ad/s
+
+# permutation:
+nperm = 1000
+ads = []
+xy = np.hstack((x, y))
+for i in range(nperm) :
+    xyp = rng.permutation(xy)
+    ads.append(np.mean(xyp[:len(x)])-np.mean(xyp[len(x):]))
+
+# histogram of shuffled data:
+hxp, _ = np.histogram(xyp[:len(x)], bins)
+hyp, _ = np.histogram(xyp[len(x):], bins)
+
+# pdf of the differences of means:
+h, b = np.histogram(ads, 20, density=True)
+
+# significance:
+dq = np.percentile(ads, 95.0)
+print('Measured difference of means = %.2f, difference at 95%% percentile of permutation = %.2f' % (ad, dq))
+da = 1.0-0.01*st.percentileofscore(ads, ad)
+print('Measured difference of means %.2f is at %.2f%% percentile of permutation' % (ad, 100.0*da))
+
+ap, at = st.ttest_ind(x, y)
+print('Measured difference of means %.2f is at %.2f%% percentile of test' % (ad, ap))
+
+
+fig = plt.figure(figsize=cm_size(figure_width, 1.8*figure_height))
+gs = gridspec.GridSpec(nrows=2, ncols=2, wspace=0.35, hspace=0.8,
+                       **adjust_fs(fig, left=5.0, right=1.5, top=1.0, bottom=2.7))
+
+ax = fig.add_subplot(gs[0,0])
+ax.bar(bins[:-1]-0.25*db, hy, 0.5*db, **fsA)
+ax.bar(bins[:-1]+0.25*db, hx, 0.5*db, **fsB)
+ax.annotate('', xy=(0.0, 45.0), xytext=(d, 45.0), arrowprops=dict(arrowstyle='<->'))
+ax.text(0.5*d, 50.0, 'd=%.1f' % d, ha='center')
+ax.set_xlim(-2.5, 2.5)
+ax.set_ylim(0.0, 50)
+ax.yaxis.set_major_locator(ticker.MultipleLocator(20.0))
+ax.set_xlabel('Original x and y values')
+ax.set_ylabel('Counts')
+
+ax = fig.add_subplot(gs[0,1])
+ax.bar(bins[:-1]-0.25*db, hyp, 0.5*db, **fsA)
+ax.bar(bins[:-1]+0.25*db, hxp, 0.5*db, **fsB)
+ax.set_xlim(-2.5, 2.5)
+ax.set_ylim(0.0, 50)
+ax.yaxis.set_major_locator(ticker.MultipleLocator(20.0))
+ax.set_xlabel('Shuffled x and y values')
+ax.set_ylabel('Counts')
+
+ax = fig.add_subplot(gs[1,:])
+ax.annotate('Measured\ndifference\nis significant!',
+            xy=(ad, 1.2), xycoords='data',
+            xytext=(ad-0.1, 2.2), textcoords='data', ha='right',
+            arrowprops=dict(arrowstyle="->", relpos=(1.0,0.5),
+                connectionstyle="angle3,angleA=-20,angleB=100") )
+ax.annotate('95% percentile',
+            xy=(0.19, 0.9), xycoords='data',
+            xytext=(0.3, 5.0), textcoords='data', ha='left',
+            arrowprops=dict(arrowstyle="->", relpos=(0.1,0.0),
+                connectionstyle="angle3,angleA=40,angleB=80") )
+ax.annotate('Distribution of\nnullhypothesis',
+            xy=(-0.08, 3.0), xycoords='data',
+            xytext=(-0.22, 4.5), textcoords='data', ha='left',
+            arrowprops=dict(arrowstyle="->", relpos=(0.2,0.0),
+                connectionstyle="angle3,angleA=60,angleB=150") )
+ax.bar(b[:-1], h, width=b[1]-b[0], **fsC)
+ax.bar(b[:-1][b[:-1]>=dq], h[b[:-1]>=dq], width=b[1]-b[0], **fsB)
+ax.plot( [ad, ad], [0, 1], **lsA)
+ax.set_xlim(-0.25, 0.85)
+ax.set_ylim(0.0, 5.0)
+ax.yaxis.set_major_locator(ticker.MultipleLocator(2.0))
+ax.set_xlabel('Difference of means')
+ax.set_ylabel('PDF of H0')
+
+plt.savefig('permuteaverage.pdf')

bootstrap/lecture/permutecorrelation.py

@@ -1,9 +1,11 @@
 import numpy as np
 import scipy.stats as st
 import matplotlib.pyplot as plt
+import matplotlib.gridspec as gridspec
+import matplotlib.ticker as ticker
 from plotstyle import *

-rng = np.random.RandomState(637281)
+rng = np.random.RandomState(37281)

 # generate correlated data:
 n = 200
@@ -22,29 +24,53 @@ for i in range(nperm) :
     xr = rng.permutation(x)
     yr = rng.permutation(y)
     rs.append(np.corrcoef(xr, yr)[0, 1])
+rr = np.corrcoef(xr, yr)[0, 1]

 # pdf of the correlation coefficients:
 h, b = np.histogram(rs, 20, density=True)

 # significance:
 rq = np.percentile(rs, 95.0)
-print('Measured correlation coefficient = %.2f, correlation coefficient at 95%% percentile of bootstrap = %.2f' % (rd, rq))
+print('Measured correlation coefficient = %.2f, correlation coefficient at 95%% percentile of permutation = %.2f' % (rd, rq))
 ra = 1.0-0.01*st.percentileofscore(rs, rd)
-print('Measured correlation coefficient %.2f is at %.4f percentile of bootstrap' % (rd, ra))
+print('Measured correlation coefficient %.2f is at %.4f percentile of permutation' % (rd, ra))

 rp, ra = st.pearsonr(x, y)
 print('Measured correlation coefficient %.2f is at %.4f percentile of test' % (rp, ra))

-fig, ax = plt.subplots(figsize=cm_size(figure_width, 1.2*figure_height))
+fig = plt.figure(figsize=cm_size(figure_width, 1.8*figure_height))
-fig.subplots_adjust(**adjust_fs(left=4.0, bottom=2.7, right=0.5, top=1.0))
+gs = gridspec.GridSpec(nrows=2, ncols=2, wspace=0.35, hspace=0.8,
+                       **adjust_fs(fig, left=5.0, right=1.5, top=1.0, bottom=2.7))
+
+ax = fig.add_subplot(gs[0,0])
+ax.text(0.0, 4.0, 'r=%.2f' % rd, ha='center')
+ax.plot(x, y, **psAm)
+ax.set_xlim(-4.0, 4.0)
+ax.set_ylim(-4.0, 4.0)
+ax.xaxis.set_major_locator(ticker.MultipleLocator(2.0))
+ax.yaxis.set_major_locator(ticker.MultipleLocator(2.0))
+ax.set_xlabel('x')
+ax.set_ylabel('y')
+
+ax = fig.add_subplot(gs[0,1])
+ax.text(0.0, 4.0, 'r=%.2f' % rr, ha='center')
+ax.plot(xr, yr, **psAm)
+ax.set_xlim(-4.0, 4.0)
+ax.set_ylim(-4.0, 4.0)
+ax.xaxis.set_major_locator(ticker.MultipleLocator(2.0))
+ax.yaxis.set_major_locator(ticker.MultipleLocator(2.0))
+ax.set_xlabel('Shuffled x')
+ax.set_ylabel('Shuffled y')
+
+ax = fig.add_subplot(gs[1,:])
 ax.annotate('Measured\ncorrelation\nis significant!',
             xy=(rd, 1.1), xycoords='data',
-            xytext=(rd, 2.2), textcoords='data', ha='left',
+            xytext=(rd-0.01, 3.0), textcoords='data', ha='left',
-            arrowprops=dict(arrowstyle="->", relpos=(0.2,0.0),
+            arrowprops=dict(arrowstyle="->", relpos=(0.3,0.0),
                 connectionstyle="angle3,angleA=10,angleB=80") )
 ax.annotate('95% percentile',
             xy=(0.14, 0.9), xycoords='data',
-            xytext=(0.18, 4.0), textcoords='data', ha='left',
+            xytext=(0.16, 6.2), textcoords='data', ha='left',
             arrowprops=dict(arrowstyle="->", relpos=(0.1,0.0),
                 connectionstyle="angle3,angleA=30,angleB=80") )
 ax.annotate('Distribution of\nuncorrelated\nsamples',
@@ -56,7 +82,9 @@ ax.bar(b[:-1], h, width=b[1]-b[0], **fsC)
 ax.bar(b[:-1][b[:-1]>=rq], h[b[:-1]>=rq], width=b[1]-b[0], **fsB)
 ax.plot( [rd, rd], [0, 1], **lsA)
 ax.set_xlim(-0.25, 0.35)
+ax.set_ylim(0.0, 6.0)
+ax.yaxis.set_major_locator(ticker.MultipleLocator(2.0))
 ax.set_xlabel('Correlation coefficient')
-ax.set_ylabel('Prob. density of H0')
+ax.set_ylabel('PDF of H0')

 plt.savefig('permutecorrelation.pdf')

chapter.mk

@@ -10,6 +10,8 @@ pythonplots : $(PYPDFFILES)

 $(PYPDFFILES) : %.pdf: %.py ../../plotstyle.py
 	PYTHONPATH="../../" python3 $<
+#ps2pdf $@ $(@:.pdf=-temp.pdf)  # strip fonts, saves only about 1.5MB
+#mv $(@:.pdf=-temp.pdf) $@

 cleanpythonplots :
 	rm -f $(PYPDFFILES)
@@ -42,6 +44,9 @@ $(BASENAME)-chapter.pdf : $(BASENAME)-chapter.tex $(BASENAME).tex $(wildcard $(B
 watchchapter :
 	while true; do ! make -q chapter && make chapter; sleep 0.5; done

+watchplots :
+	while true; do ! make -q plots && make plots; sleep 0.5; done
+
 cleantex:
 	rm -f *~
 	rm -f $(BASENAME).aux $(BASENAME).log *.idx

codestyle/lecture/codestyle.tex

@@ -4,6 +4,7 @@
   more months might as well have been written by someone
   else.}{Eagleson's law}

+\noindent
 Cultivating a good code style is not just a matter of good taste but
 rather is a key ingredient for readability and maintainability of code
 and, in the end, facilitates reproducibility of scientific
@@ -204,7 +205,7 @@ random walk\footnote{A random walk is a simple simulation of Brownian
 (listing \ref{chaoticcode}) then in cleaner way (listing
 \ref{cleancode})

-\begin{lstlisting}[label=chaoticcode, caption={Chaotic implementation of the random-walk.}]
+\begin{pagelisting}[label=chaoticcode, caption={Chaotic implementation of the random-walk.}]
 num_runs = 10; max_steps = 1000;

 positions = zeros(max_steps, num_runs);
@@ -218,17 +219,14 @@ x = randn(1);
 if x<0
 positions(step, run)= positions(step-1, run)+1;

-
 elseif x>0
  positions(step,run)=positions(step-1,run)-1;
  end
 end
 end
-\end{lstlisting}
+\end{pagelisting}

-\pagebreak[4]
+\begin{pagelisting}[label=cleancode, caption={Clean implementation of the random-walk.}]
-
-\begin{lstlisting}[label=cleancode, caption={Clean implementation of the random-walk.}]
 num_runs = 10;
 max_steps = 1000;
 positions = zeros(max_steps, num_runs);
@@ -243,7 +241,7 @@ for run = 1:num_runs
         end
     end
 end
-\end{lstlisting}
+\end{pagelisting}

 \section{Using comments}

@@ -275,7 +273,6 @@ avoided:\\ \varcode{ x = x + 2; \% add two to x}\\
     make it even clearer.}{Steve McConnell}
 \end{important}

-\pagebreak[4]
 \section{Documenting functions}
 All pre-defined \matlab{} functions begin with a comment block that
 describes the purpose of the function, the required and optional
@@ -335,8 +332,7 @@ used within the context of another function \matlab{} allows to define
 within the same file. Listing \ref{localfunctions} shows an example of
 a local function definition.

-\pagebreak[3]
+\pageinputlisting[label=localfunctions, caption={Example for local
-\lstinputlisting[label=localfunctions, caption={Example for local
   functions.}]{calculateSines.m}

 \emph{Local function} live in the same \entermde{m-File}{m-file} as

debugging/lecture/debugging.tex

@@ -59,14 +59,14 @@ every opening parenthesis must be matched by a closing one or every
 respective error messages are clear and the editor will point out and
 highlight most syntax errors.

-\begin{lstlisting}[label=syntaxerror, caption={Unbalanced parenthesis error.}]
+\begin{pagelisting}[label=syntaxerror, caption={Unbalanced parenthesis error.}]
 >> mean(random_numbers
                       |
 Error: Expression or statement is incorrect--possibly unbalanced (, {, or [.

 Did you mean:
 >>   mean(random_numbers)
-\end{lstlisting}
+\end{pagelisting}

 \subsection{Indexing error}\label{index_error}
 Second on the list of common errors are the
@@ -125,7 +125,7 @@ dimensions. The command in line 7 works due to the fact, that matlab
 automatically extends the matrix, if you assign values to a range
 outside its bounds.

-\begin{lstlisting}[label=assignmenterror, caption={Assignment errors.}]
+\begin{pagelisting}[label=assignmenterror, caption={Assignment errors.}]
 >> a = zeros(1, 100);
 >> b = 0:10;

@@ -136,7 +136,7 @@ outside its bounds.
 >> size(a)
 ans =
      110    1
-\end{lstlisting}
+\end{pagelisting}

 \subsection{Dimension mismatch error}
 Similarly, some arithmetic operations are only valid if the variables
@@ -154,7 +154,7 @@ in listing\,\ref{dimensionmismatch} does not throw an error but the
 result is something else than the expected elementwise multiplication.

 % XXX Some arithmetic operations make size constraints, violating them leads to dimension mismatch errors.
-\begin{lstlisting}[label=dimensionmismatch, caption={Dimension mismatch errors.}]
+\begin{pagelisting}[label=dimensionmismatch, caption={Dimension mismatch errors.}]
   >> a = randn(100, 1);
   >> b = randn(10, 1);
   >> a + b
@@ -171,7 +171,7 @@ result is something else than the expected elementwise multiplication.
   >> size(c)
   ans =
        100    10
-\end{lstlisting}
+\end{pagelisting}



@@ -239,7 +239,7 @@ but it requires a deep understanding of the applied functions and also
 the task at hand.

 % XXX Converting a series of spike times into the firing rate as a function of time. Many tasks can be solved with a single line of code. But is this readable?
-\begin{lstlisting}[label=easyvscomplicated, caption={One-liner versus readable code.}]
+\begin{pagelisting}[label=easyvscomplicated, caption={One-liner versus readable code.}]
 % the one-liner
 rate = conv(full(sparse(1, round(spike_times/dt), 1, 1, length(time))), kernel, 'same');

@@ -248,7 +248,7 @@ rate = zeros(size(time));
 spike_indices = round(spike_times/dt);
 rate(spike_indices) = 1;
 rate = conv(rate, kernel, 'same');
-\end{lstlisting}
+\end{pagelisting}

 The preferred way depends on several considerations. (i) How deep is
 your personal understanding of the programming language?  (ii) What
@@ -291,7 +291,7 @@ example given in the \matlab{} help and assume that there is a
 function \varcode{rightTriangle()} (listing\,\ref{trianglelisting}).

 % XXX Slightly more readable version of the example given in the \matlab{} help system. Note: The variable name for the angles have been capitalized in order to not override the matlab defined functions \code{alpha, beta,} and \code{gamma}.
-\begin{lstlisting}[label=trianglelisting, caption={Example function for unit testing.}]
+\begin{pagelisting}[label=trianglelisting, caption={Example function for unit testing.}]
 function angles = rightTriangle(length_a, length_b)
     ALPHA = atand(length_a / length_b);
     BETA = atand(length_a / length_b);
@@ -300,7 +300,7 @@ function angles = rightTriangle(length_a, length_b)

     angles = [ALPHA BETA GAMMA];
 end
-\end{lstlisting}
+\end{pagelisting}

 This function expects two input arguments that are the length of the
 sides $a$ and $b$ and assumes a right angle between them. From this
@@ -337,7 +337,7 @@ The test script for the \varcode{rightTriangle()} function
 (listing\,\ref{trianglelisting}) may look like in
 listing\,\ref{testscript}.

-\begin{lstlisting}[label=testscript, caption={Unit test for the \varcode{rightTriangle()} function stored in an m-file testRightTriangle.m}]
+\begin{pagelisting}[label=testscript, caption={Unit test for the \varcode{rightTriangle()} function stored in an m-file testRightTriangle.m}]
 tolerance = 1e-10;

 % preconditions
@@ -373,7 +373,7 @@ angles = rightTriangle(1, 1500);
 smallAngle = (pi / 180) * angles(1); % radians
 approx = sin(smallAngle);
 assert(abs(approx - smallAngle) <= tolerance, 'Problem with small angle approximation')
-\end{lstlisting}
+\end{pagelisting}

 In a test script we can execute any code. The actual test whether or
 not the results match our predictions is done using the
@@ -390,16 +390,16 @@ executed. We further define a \varcode{tolerance} variable that is
 used when comparing double values (Why might the test on equality of
 double values be tricky?).

-\begin{lstlisting}[label=runtestlisting, caption={Run the test!}]
+\begin{pagelisting}[label=runtestlisting, caption={Run the test!}]
 result = runtests('testRightTriangle')
-\end{lstlisting}
+\end{pagelisting}

 During the run, \matlab{} will put out error messages onto the command
 line and a summary of the test results is then stored within the
 \varcode{result} variable. These can be displayed using the function
 \code[table()]{table(result)}.

-\begin{lstlisting}[label=testresults, caption={The test results.}, basicstyle=\ttfamily\scriptsize]
+\begin{pagelisting}[label=testresults, caption={The test results.}, basicstyle=\ttfamily\scriptsize]
 table(result)
 ans =
   4x6 table
@@ -411,7 +411,7 @@ _________________________________   ______  ______  ___________  ________  _____
 'testR.../Test_IsoscelesTriangles'   true   false   false        0.004893   [1x1 struct]
 'testR.../Test_30_60_90Triangle'     true   false   false        0.005057   [1x1 struct]
 'testR.../Test_SmallAngleApprox'     true   false   false        0.0049     [1x1 struct]
-\end{lstlisting}
+\end{pagelisting}

 So far so good, all tests pass and our function appears to do what it
 is supposed to do. But tests are only as good as the programmer who
@@ -479,11 +479,11 @@ stopped in debug mode (listing\,\ref{debuggerlisting}).
 \end{figure}


-\begin{lstlisting}[label=debuggerlisting, caption={Command line when the program execution was stopped in the debugger.}]
+\begin{pagelisting}[label=debuggerlisting, caption={Command line when the program execution was stopped in the debugger.}]
 >> simplerandomwalk
 6   for run = 1:num_runs
 K>>
-\end{lstlisting}
+\end{pagelisting}

 When stopped in the debugger we can view and change the state of the
 program at this point, we can also issue commands to try the next

designpattern/lecture/designpattern.tex

@@ -10,7 +10,8 @@ pattern]{design pattern}.
 %%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%
 \section{Looping over  vector elements}
 Iterating over vector elements by means of a \mcode{for}-loop is a very commen pattern:
-\begin{lstlisting}[caption={\varcode{for}-loop for accessing vector elements by indices}]
+
+\begin{pagelisting}[caption={\varcode{for}-loop for accessing vector elements by indices}]
 x = [2:3:20];      % Some vector.
 for i=1:length(x)  % For loop over the indices of the vector.
   i                % This is the index (an integer number)
@@ -22,12 +23,14 @@ for i=1:length(x)  % For loop over the indices of the vector.
   % as an argument to a function:
   do_something(x(i));
 end
-\end{lstlisting}
+\end{pagelisting}

+\noindent
 If the result of the computation within the loop are single numbers
 that are to be stored in a vector, you should create this vector with
 the right size before the loop:
-\begin{lstlisting}[caption={\varcode{for}-loop for writing a vector}]
+
+\begin{pagelisting}[caption={\varcode{for}-loop for writing a vector}]
 x = [1.2 2.3 2.6 3.1];   % Some vector.
 % Create a vector for the results, as long as the number of loops:
 y = zeros(length(x),1);
@@ -38,13 +41,15 @@ for i=1:length(x)
 end
 % Now the result vector can be further processed:
 mean(y);
-\end{lstlisting}
+\end{pagelisting}

+\noindent
 The computation within the loop could also result in a vector of some
 length and not just a single number. If the length of this vector
 (here 10) is known beforehand, then you should create a matrix of
 appropriate size for storing the results:
-\begin{lstlisting}[caption={\varcode{for}-loop for writing rows of a matrix}]
+
+\begin{pagelisting}[caption={\varcode{for}-loop for writing rows of a matrix}]
 x = [2:3:20];             % Some vector.
 % Create space for results -
 % as many rows as loops, as many columns as needed:
@@ -56,30 +61,33 @@ for i=1:length(x)
 end
 % Process the results stored in matrix y:
 mean(y, 1)
-\end{lstlisting}
+\end{pagelisting}

+\noindent
 Another possibility is that the result vectors (here of unknown size)
 need to be combined into a single large vector:
-\begin{lstlisting}[caption={\varcode{for}-loop for appending vectors}]
+
+\begin{pagelisting}[caption={\varcode{for}-loop for appending vectors}]
 x = [2:3:20];        % Some vector.
 y = [];              % Empty vector for storing the results.
 for i=1:length(x)
   % The function get_something() returns a vector of unspecified size:
-  z = get_somehow_more(x(i));
+  z = get_something(x(i));
   % The content of z is appended to the result vector y:
-  y = [y; z(:)];
+  y = [y, z(:)];
   % The z(:) syntax ensures that we append column-vectors.
 end
-% Process the results stored in the vector z:
+% Process the results stored in the vector y:
-mean(y)
+mean(y, 1)
-\end{lstlisting}
+\end{pagelisting}


 %%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%
 \section{Scaling and shifting random numbers, zeros, and ones}
 Random number generators usually return random numbers of a given mean
 and standard deviation. Multiply those numbers by a factor to change their standard deviation and add a number to shift the mean.
-\begin{lstlisting}[caption={Scaling and shifting of random numbers}]
+
+\begin{pagelisting}[caption={Scaling and shifting of random numbers}]
 % 100 random numbers drawn from a normal distribution
 % with mean 0 and standard deviation 1:
 x = randn(100, 1);
@@ -89,18 +97,20 @@ x = randn(100, 1);
 mu = 4.8;
 sigma = 2.3;
 y = randn(100, 1)*sigma + mu;
-\end{lstlisting}
+\end{pagelisting}

+\noindent
 The same principle can be useful for in the context of the functions
 \mcode{zeros()} or \mcode{ones()}:
-\begin{lstlisting}[caption={Scaling and shifting of \varcode{zeros()} and \varcode{ones()}}]
+
+\begin{pagelisting}[caption={Scaling and shifting of \varcode{zeros()} and \varcode{ones()}}]
 x = -1:0.01:2;      % Vector of x-values for plotting
 plot(x, exp(-x.*x));
 % Plot for the same x-values a horizontal line with y=0.8:
 plot(x, zeros(size(x))+0.8);
 % ... or a line with y=0.5:
 plot(x, ones(size(x))*0.5);
-\end{lstlisting}
+\end{pagelisting}


 %%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%
@@ -119,25 +129,26 @@ can plot the values of the $y$ vector against the ones of the $x$
 vector.

 The following scripts compute and plot the function $f(x)=e^{-x^2}$:
-\begin{lstlisting}[caption={Plotting a mathematical function --- very detailed}]
+
+\begin{pagelisting}[caption={Plotting a mathematical function --- very detailed}]
 xmin = -1.0;
 xmax = 2.0;
 dx = 0.01;        % Step size
 x = xmin:dx:xmax; % Vector with x-values.
 y = exp(-x.*x);   % No for loop! '.*' for multiplying the vector elements.
 plot(x, y);
-\end{lstlisting}
+\end{pagelisting}

-\begin{lstlisting}[caption={Plotting a mathematical function --- shorter}]
+\begin{pagelisting}[caption={Plotting a mathematical function --- shorter}]
 x = -1:0.01:2;
 y = exp(-x.*x);
 plot(x, y);
-\end{lstlisting}
+\end{pagelisting}

-\begin{lstlisting}[caption={Plotting a mathematical function --- compact}]
+\begin{pagelisting}[caption={Plotting a mathematical function --- compact}]
 x = -1:0.01:2;
 plot(x, exp(-x.*x));
-\end{lstlisting}
+\end{pagelisting}


 %%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%
@@ -146,28 +157,34 @@ For estimating probabilities or probability densities from histograms
 we need to normalize them appropriately.

 The \mcode{histogram()} function does this automatically with the appropriate arguments:
-\begin{lstlisting}[caption={Probability density with the \varcode{histogram()}-function}]
+
+\begin{pagelisting}[caption={Probability density with the \varcode{histogram()}-function}]
 x = randn(100, 1);         % Some real-valued data.
 histogram(x, 'Normalization', 'pdf');
-\end{lstlisting}
+\end{pagelisting}
-\begin{lstlisting}[caption={Probability with the \varcode{histogram()}-function}]
+
+\begin{pagelisting}[caption={Probability with the \varcode{histogram()}-function}]
 x = randi(6, 100, 1);      % Some integer-valued data.
 histogram(x, 'Normalization', 'probability');
-\end{lstlisting}
+\end{pagelisting}
+
+\noindent
 Alternatively one can normalize the histogram data as returned by the
 \code{hist()}-function manually:
-\begin{lstlisting}[caption={Probability density with the \varcode{hist()}- and \varcode{bar()}-function}]
+
+\begin{pagelisting}[caption={Probability density with the \varcode{hist()}- and \varcode{bar()}-function}]
 x = randn(100, 1);         % Some real-valued data.
 [h, b] = hist(x);          % Compute histogram.
 h = h/sum(h)/(b(2)-b(1));  % Normalization to a probability density.
 bar(b, h);                 % Plot the probability density.
-\end{lstlisting}
+\end{pagelisting}
-\begin{lstlisting}[caption={Probability with the \varcode{hist()}- and \varcode{bar()}-function}]
+
+\begin{pagelisting}[caption={Probability with the \varcode{hist()}- and \varcode{bar()}-function}]
 x = randi(6, 100, 1);      % Some integer-valued data.
 [h, b] = hist(x);          % Compute histogram.
 h = h/sum(h);              % Normalize to probability.
 bar(b, h);                 % Plot the probabilities.
-\end{lstlisting}
+\end{pagelisting}


 %%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%
